ST-72 Handheld Fiber Inspection Probe

ST-72 Handheld Fiber Inspection Probe

Field Fiber Microscope is a low cost and high quality fiber inspection tool which is available in 400X magnification and the white LED light to provide coaxial illumination to connector end-faces. This is method of illumination products high-resolution detail of end-face scratches, defects and conta

 Specifications:

ST-72 Handheld Fiber Inspection Probe

Fiber Microscope is a low cost and high quality fiber inspection tool which is available in 400X magnification and the white LED light to provide coaxial illumination to connector end-faces. This is method of illumination products high-resolution detail Hand Held Fiber Microscope is used for inspecting fiber terminations, providing the most critical view of fiber and faces. Coaxial illumination (CL) series produces excellent detail of scratches and contamination with its good optical performance and integrated laser safety filters. It is the clear choice for critical examination of polish quality. Light is introduced into the optical path (axis) so that it comes out the tip of the objective and strikes the sample perpendicular to the fiber end-face. It produces excellent details of scratches and contamination. For critical examination of polish qality, we strongly recommend you to use this fiber microscope (CL).



Specifications:

  • Housing Material: Aluminum with Silver(gray) painting
  • Optical Magnification: 400x
  • Power Source: 3 pieces of AAA batteries (not included)
  • Light Source: White LED, rated for 100,000 hours
  • Weight: 0.6 Kg
  • Size: 225mm (8.76") Length x 32mm (1.25") Diameter
  • Controls: Momentary on/off switch for light source, Fine Focus control wheel
  • Safety Filter: Built-in IR filter
  • Adapter Interface: User interchangeable adapters
  • Adapter: Universal Adapter (2.5mm) Compatible with ST, FC, SC, E2000, and 2.5mm DIN
  •  Equipped with LED illumination and a Laser filter installed for eye protection
  • Comes with a versatile adapter interface
  • Provides clear bright images and smooth focus control
  • Momentary push button on/off switch
  • Long life, durable and reliable
  • Approved by strict quality and safety standards ensures a long and trouble free life
  • Approved with CE and Passes the European Standards which ensures high standard of quality



Laser Safety Attention

  • Do not use any our Fiber Inspection Microscopes to view active fiber signals under any circumstances. active fiber signals contain high-powered laser light, it can do much harm to the eyes. so we must avoid contracting with the laser light using direct eyes. the failure to avoid direct eyes contact with laser light can result in serious damage to the eye.
  • Especially , our Fiber Inspection Microscopes may magnify the laser light in active fiber signals; direct eye contact with magnified laser light should be avoided. Laser safety filters, as used in our Fiber Inspection Microscopes, are no substitute for practicing good laser safety.
