OptoTest Bidirectional ILRL Test System

OptoTest Bidirectional ILRL Test System

The OP725 is an optical switch for single mode or multimode applications available in a slim-line, half-rack enclosure. This optical switch is USB powered and incorporates the latest technology in high-speed switching. With high repeatability and low loss, the OP725 is ideally suited for bidirectio

 Specifications:

OP725-OP940 Bidirectional IL/RL Test System

The OP725 is an optical switch for single mode or multimode applications available in a slim-line, half-rack enclosure. This optical switch is USB powered and incorporates the latest technology in high-speed switching.  With high repeatability and low loss, the OP725 is ideally suited for bidirectional testing.

Paired with our OP940 Insertion & Return Loss Meter, operators can make quick work of measuring both ends of cables in a truly bidirectional manner.

The OP725 can be connected to the OP940 via USB to allow control of bidirectional switching via the OP940抯 front panel controls or in OPL-PRO software.

It can also be used in more complex, multi-instrument configurations with other OptoTest instruments
(for example, an OP710) and OPL-MAX / OPL-LOG software.

Features:

Fully automated, concurrent dual wavelength IL and RL measurements with no mandrel wrapping
Bidirectional operation; measuring total insertion loss and individual return loss
External power meter for uni-directional operation
On-board, InGaAs optical power meter features measurement range reaching -65dBm
Available in multimode and single mode
Quad-wavelength (FTTX) single mode model also available upon request
Controlled launch condition (underfill, fully filled, overfill) available for multimode fiber
Wide dynamic range on return loss measurements:
10dB to 80dB for single mode
10dB to 58dB for multimode
Can be controlled remotely via USB using
OPL series software or OptoTest DLLs
Integrated temperature monitoring
Convenient benchtop size (19-inch rackmount frame available upon request)
