Acitve Copper Cable 10G SFP+

Acitve Copper Cable 10G SFP+

The SFP+ active cable assemblies are high performance, cost effective I/O solutions for 10Gb Ethernetand 10G Fiber Channel applications. SFP+ copper modules allow hardware manufactures to achievehigh port density, configurability and utilization at a very low cast and reduced power budget. The h

 Specifications:

Product Description

The SFP+ active cable assemblies are high performance, cost effective I/O solutions for 10Gb Ethernet
and 10G Fiber Channel applications. SFP+ copper modules allow hardware manufactures to achieve
high port density, configurability and utilization at a very low cast and reduced power budget. The high
speed cable assemblies meet and exceed Gigabit Ethernet and Fiber Channel industry standard requirements
for performance and reliability.

Features
 Support for multi-gigabit data rates up to
10 Gb/s
 Data rates backward compatible to 1 Gb/s
 Hot-pluggable SFP 20PIN footprint
 Improved Pluggable Form Factor(IPF)
compliant for enhanced EMI/EMC
performance
 Low Power Consumption < 0.2W
 Power Supply :+3.3V
 Compatible to SFP+ MSA
 Compatible to SFF-8431,SFF8432
 Temperature Range: 0~ 70 C
 RoHS Compatible
Applications
 High capacity I/O in Storage Area Networks, Network Attached Storage, and Storage Servers
 Switched fabric I/O such as ultra high bandwidth switches and routers
 Data center cabling infrastructure
 High density connections between networking equipment

Recommended Operating Conditions
Parameter Symbol Min Typical Max Unit
Storage Ambient Temperature -40 +85 C
Operating Case Temperature Tc 0 +70 C
Power Supply Voltage VCC3 3.14 3.3 3.47 V
Power Dissipation PD 0.2 W
Systems
Performance Media Operating parameters
10Gb/s line speed, full duplex
Bit error rate: better than 10E-12
Hot-pluggable, industry-standard Small
Form-Factor
Pluggable(SFP+) copper cable,
available max 15m
Supply voltage: 3.3V
Power consumption(per end): max 0.2W
Pin Descriptions
Pin Logic Symbol Name/Description Notes
1 VeeT Transmitter Ground
2 LV-TTL-O TX_Fault N/A 1
3 LV-TTL-I TX_DIS Transmitter Disable
4 LV-TTL-I/O SDA Tow Wire Serial Data
5 LV-TTL-I SCL Tow Wire Serial Clock
6 MOD_DEF0 Module present, connect to VeeT
7 LV-TTL-I RS0 N/A 1
8 LV-TTL-O LOS LOS of Signal
9 LV-TTL-I RS1 N/A 1
10 VeeR Reciever Ground
11 VeeR Reciever Ground
12 CML-O RD- Reciever Data Inverted
13 CML-O RD+ Reciever Data Non-Inverted
14 VeeR Reciever Ground
15 VccR Reciever Supply 3.3V
16 VccT Transmitter Supply 3.3V
17 VeeT Transmitter Ground
18 CML-I TD+ Transmitter Data Non-Inverted Page 3 of 4 5 /2014
19 CML_I TD- Transmitter Data Inverted
20 VeeT Transmitter Ground
1. Signals not supported in SFP+ Copper pulled-down to VeeT with 30K ohms resistor
