ST-3226 CWDM Optic Power Meter

ST-3226 CWDM Optic Power Meter

ST-3226 CWDM Optic Power Meter is a handy measuring which is specially designed for CWDM system, covers wavelength from 1470-1610nm. It can measure and monitor optical power and attenuation value at the calibrated wavelengths of 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm . Testing at all cali

 Specifications:


ST-3226 CWDM Optic Power Meter is a handy measuring which is specially designed for CWDM system, covers wavelength from 1470-1610nm. It can measure and monitor optical power and attenuation value at the calibrated wavelengths of 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm  . Testing at all calibrated wavelengths will be performed simultaneously and all testing results will be showed in the LCD display. 3226CWDM power meter features simple operation and quick response, which greatly improves the testing efficiency. Its high accuracy measurement and easy-to-use design becomes an ideal tester in CWDM system testing and CWDM installation and maintenance. Simple to operate , greatly improve the working efficiency.

Key Features
CWDM System testing special purpose.
Test at all calibrated wavelength performed & showed simultaneously
500 items storage & upload by USB .

Specifications

Model

ST-3226

Pass band(nm)

20

Wavelength  range(nm)

1470-1610

Calibrated  wavelength(nm)

1470, 1490,  1510, 1530, 1550, 1570, 1590, 1610

Optical Power  Range(dBm)

-50-+3

Uncertainty(dB)

±0.4

Resolution

0.01

Data Storage

500 sets

Communication  Port

USB

Auto Power-off  (min)

10 minutes

Power supply adaptor

8.4V

Operation  temperature

-10~60°C

Operation Time

120 hours

Storage  temperature

-25~70°C

Packing & Delivery:



G.W.

420G

Packing sizes

180mm(L)*90mm(W)*36.5mm(H)
