Fiber-Mart's 1x8 MEMS Bi-directional Fiber Optical switch, based on Microelectromechanical Systems (MEMS) technology, is a compact optical switch which connect optical channels by redirecting 1 incoming optical signals into 8 selected output fibers. The switching state is highly stable against environmental variations of temperature and vibration due to its unique design. This novel design significantly reduces packaging requirement, and simplifies driving electronics, offering unprecedented high stability as well as an unmatched low cost.
Fiber-Mart offers most affordable high performance MEMS optical switches. The MEMS technology offers extremely low electrical power consumption, high durability (> 1x10^9 cycles), no stiction, and high resistance to shock & vibration. Laser welded assembly ensures repeatability and ruggedness in field applications. Our MEMS Switches are tested in-house prior to shipment to guarantee that they will arrive in perfect physical and working condition. Currently configurations includes 1x4, 1x8 and 1x16 configurations for single-mode or multimode fibers, available in either latching or non latching variants.
Features
|
Applications
|
Parameters | Unit | MSW-1x8 |
Wavelength Range | nm | 1260 ~ 1620 |
Testing Wavelength | nm | 1310/1490/1550/1625/1650 |
Insertion Loss | dB | Typ: 0.7 , Max: 1.2 |
Return Loss | dB | ≥ 50 |
Crosstalk | dB | ≥ 50 |
PDL | dB | ≤ 0.10 |
WDL | dB | ≤ 0.25 |
TDL | dB | ≤ 0.20 |
Repeatability | dB | ≤ ±0.05 |
Repeatability Rate | Hz | 20 |
Lifetime | Cycle | ≥ 109 |
Switch Time | ms | ≤ 5 |
Transmission Power | mW | ≤ 500 |
Operation Temperature | oC | -5 ~ +70 |
Storage Temperature | oC | -40 ~ +85 |
Dimension | mm | (L)42 x (W)26 x (H)9.4 (±0.2) |
Mechanical Dimensions (Unit: mm)
This series of switches is designed to meet the most demanding Carrier-class and out-door optical switching applications.
Together with contorl electronics, the switch can be controlled through digital interfaces. Fiber-Mart also offers External TTL and External IIC interfaces as an option-please contact Fiber-Mart sales at [email protected].
Optical Path | Pin 1 | Pin 2 | Pin 3 | Pin 4 | Pin 5 | Pin 6 | Pin 7 | Pin 8 | Pin 9 | Pin 10 | Pin 11 | Pin 12 | Pin 13 | Pin 14 | Pin 15 | Pin 16 |
Comm↔Port 1 | DP* | NC | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | GND | |
Comm↔Port 2 | NC | DP | DP | NC | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | ||
Comm↔Port 3 | NC | DP | NC | DP | DP | NC | NC | DP | NC | DP | NC | DP | NC | DP | ||
Comm↔Port 4 | NC | DP | NC | DP | NC | DP | DP | NC | NC | DP | NC | DP | NC | DP | ||
Comm↔Port 5 | NC | DP | NC | DP | NC | DP | NC | DP | DP | NC | NC | DP | NC | DP | ||
Comm↔Port 6 | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | DP | NC | NC | DP | ||
Comm↔Port 7 | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | DP | NC | ||
Comm↔Port 8 | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP | NC | DP |
* DP: Driving Pulse Voltage
DrivingPulse | Min | Typical | Max | Unit |
Pulsevoltage | 9 | 9.3 | 9.5 [ 4 ] | V |
Pulsewidth | 12 | 12.5 | 13 [ 4 ] | ms |
Peakcurrent | 290 | mA |
Attention! Outside this range could damage the device.
Order Information:MSW-1×8-A-B-C-D-E
A | B | C | D | E |
Mode | Wavelength | Fiber Diameter | Fiber Length | Connector |
SM: 9/125um | 85: 850nm | 25: 250um | 05: 0.5m | OO: None |
M5: 50/125um | 13: 1310nm | 90: 900um | 10: 1.0m | FP: FC/PC |
M6: 62.5/125um | 14: 1490nm | S: Special | 15: 1.5m | FA: FC/APC |
S: Special | 15: 1550nm | S: Special | SP: SC/PC | |
162: 1625nm | SA: SC/APC | |||
165: 1650nm | LP: LC/PC | |||
13/15: 1310/1550nm | LA: LC/APC | |||
S: Special | SP: ST/PC | |||
SA: ST/APC | ||||
S: Special |
For example: MSW-1x8-M6-13-S-15-FP
